  • Intel N5100 quad-core + Windows 11 Pro

Enough power to run demanding fleet and logistics software. Full Windows means your existing tools work straight out of the box.

  • Customisable

Programmable function keys so operators can access key commands without navigating menus — useful for drivers who need quick access without taking eyes off the road.

  • Stable Power Supply

Vehicle power via military-grade circular connector — can also be adapted to standard 12V cigarette lighter socket or 5.5mm barrel plug. Powered directly from your vehicle’s electrical system.

  • Flexible Extension

Built-in Connectivity: USB ports, Ethernet (LAN), RS232 serial for legacy hardware, CAN bus for vehicle diagnostics, plus multiple expansion ports for custom integrations.

  • Enhanced Robustness

IP65 dustproof and waterproof, morphed to endure outdoor applications prone to shock, vibration and extreme temperature

  • 3-year return-to-base warranty included

If it fails, we fix it or replace it — no arguments. That’s the commitment behind every ONERUGGED unit.

Price (RRP/Excl GST):

Price range: $1,515.00 through $1,715.00

Brand:

ONERUGGED

Description

Field teams and fleet operators run into the same problems with consumer hardware: screens you can’t read in the sun, tablets that freeze in the cold, power adapters that come loose on rough roads, and IT headaches when Windows updates don’t play nice with a locked-down device.

The ONERUGGED Windows Vehicle PC is designed specifically for demanding in-vehicle environments — permanently mounted in the cab via aviation-grade connector, powered directly from the vehicle’s electrical system (6–36V, ignition-switched), and running full Windows 11 Pro so your existing software just works.

Tested to IP65, MIL-STD-810H, and ISO vehicle power standards, it handles the vibration, shock, temperature extremes, and power fluctuations that kill consumer hardware within months.

Why Windows?

If your team already runs Windows-based dispatch software, ERP systems, or logistics platforms, this is the unit that works without compromise. No Android app workarounds, no compatibility testing, no IT headaches. Full Windows 11 Pro means your drivers can access the same software they use at the office — connected to your network, managed by your IT team, exactly as configured.

If you’re not sure whether Windows or Android is right for your fleet,  get in touch →  — we’ll help you work it out.

Additional information

PC screen model

10" Vehicle PC Win 11 Pro 8GB/128GB SSD, 4G, 8" Vehicle PC Win 11 Pro 8GB/128GB SSD, 4G

Appearance

Dimensions: 218.1×154.5×23.0mm
Weight: 620g

Display: Size:

Type: LCD
Size: 8 & 10.1 inch 16:10
Resolution:  800*1280 IPS
Brightness: 1000cd/㎡
Touch Panel: 5-point tempered glass capacitive screen G+G, hardness 7H

Performance

Processor: Intel JASPER LAKE N5100 Max 2.8GHz
Operating System: Windows 11 Pro
Memory+Storage: RAM: 8GB (LPDDR3) ROM: 128GB (EMMC)
Battery (optional): Built-in polymer lithium-ion battery, 1000mAh/7.4V
RTC Battery: Built-in RTC battery
Power: Power adapter cable (M12-8 power port to φ5.5 power port) Optional: φ5.5 adapter (input AC 100V~240V 50Hz/60Hz, output DC 19V/3.42A)

Wireless

WiFi: 802.11 (a/b/g/n/ac), 2.4G+5.8G dual frequency Standard WiFi rod antenna
WAN (optional): 4G Optional 4G rod antenna
Bluetooth: Bluetooth 5.0
GNSS: GPS+GLONASS, optional Beidou Standard GPS rod antenna
NFC (optional)

Ruggedness

IP Ratings: IP65
Temperature: Working temperature: -20 °C to 60 °C Storage temperature: -30 °C to 70 °C
ESD Protection: ±15kV air discharge ±8kV contact discharge

Downloads

Specification sheet

User manual

What is in the box

Vehicle-mount terminal Wi-Fi rod antenna: 2.4~2.5GHZ /5.15~5.85GHz ，2±0.5 dBi GPS rod antenna 4G rod antenna Power adapter cable: 8 PIN aviation plug φ 5.5 The power supply port (suitable for cigarette lighter, car charger, etc.) is 30CM long Power adapter cable: Transfer 8-pin power lines to 8 loose wires (1.2M) RAM 75mm x 75mm Vesa plate

Optional extras

Cigarette lighter adapter, Mains power adapter, wide voltage power regulator, Multi-function adapter selection 12PIN to 2-way USB 1-way CAN, Multi-function adapter selection 12PIN to full function RS232 power line + serial communication 485, Multi-function adapter selection 12PIN to 1000M RJ45, Multi-function adapter selection 12PIN to 12 loose wires 1.2m, Active GPS mushroom antenna, line length 1.5M, 20dB ± 2dB, Battery 1000mAh/7.4V Please check with us for pricing.
